Tek 7834 + 54 plugins 62(+) vol 2 cd manual set
Tektronix 7834 Service/Op Manual Plus Sixty One 7000-Series Plugin Manuals (for 54 different Plug-Ins) in PDF in a 2-CD Set
->Standard Res Samples<-(7834 & Plugins)
For page samples from the specific Reproduction Grade manual (7834) included, click HERE. Please note that the list is alphabetized by model and not by manufacturer.
These manuals cover the Tektronix Model 7834 oscilloscope frame plus a substantial number of plugins (see list below). They are all scanned from the original Tektronix commercial manuals. The scans came out well, and all information available in the original manuals is available here.
Two PDFs of the Oscilloscope Mainframe manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Any Schematics, board overlays with color notes at 600dpi 256 colors
Here's a listing of the plugin manuals included. This is not a choice of manuals, you get them ALL!
As a "bonus", includes the Tektronix publication "Tektronix 7000 Series Digital Plug-in Applications" (time and frequency, digital delay, amplitude, temperature) at no additional charge. Please note that this is not included in the "volume count".
