> Tek TM5006 manual + 38 TM500-series plugin manuals
Tek TM5006 manual + 38 TM500-series plugin manuals
Tektronix TM5006 Plus Plug Ins Service Manual in PDF on CD
These manuals cover the Tektronix Model TM5006 Power Module plus a large number of plugins for the TM500 Series (please note: TM500, not TM-5000). They are scanned from the original manufacturer's manuals. The scans came out well, and all information available in the original manuals is available and readable here.
Two PDFs of the Power Module manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Schematics, board overlays that have color notes at 600dpi 256 colors
This resolution looks nice, but for many purposes uses excessive resources. You can copy the large file to the hard drive to achieve better performance, but such a necessity is certainly of no benefit to you.
We include both resolutions so you can see for yourself that huge resolutions are nice to look at, but there's seldom any reason to stuff your system with them if you are a technician or engineer doing electronics work with these manuals.
Here's a listing of the plugin manuals included. This is not a choice of manuals, you get them ALL!
(Please note that not all of the modules in this list fit electrically into the TM5006. There are no TM5000-specific modules in this manual group)
ALL original manual pages are supplied. Some vendors advertise page counts which are inflated by the addition of advertising and blank pages, which increase their page count and allows them to appear to be supplying a more comprehensive document. Rather than resort to such deceptive practice, we assure you that these manuals are complete.
