Deutz allis tractor control valve service manual book
ORIGINAL!! Deutz Allis Service Training Manual for the Auxiliary Control Valves SD80 Mower Control Valves. Manual number 0298 6351, dated 1986 and has 50 pages. This manual has very detailed repair information. The same genuine Deutz Allis manual your dealer's mechanic received at training shcool. Just what you need to to your own repairs!
It's divided into 14 sections:
2)Explanation of the Designation SD 80
3 External Identification Points
4)Common Functions - symbols, precision control, positive switch overlapping, applications, raising & lowering connections, actuation of the auxiliary control valves
5)Series Connection: Neutral Flow State
6)Control Functions - neutral, raising, lowering & floating position
7)SD 80 I - data sheet: SD80 I, detent with check valve, raising & lowering process
8)SD 80 II - data sheet SD 80 II
9)SD 80 III - data sheet SD 80 III
10)Hydraulic Detent Release System - SD 80 I and SD 80 II
11)Layout: Auxiliary Control Valve to Hydraulic Female Coupler at Rear of Tractor - hydraulic remote connections via couplers of non-breakaway type (pipings laid at points 1 and 2), hydraulic remote connections via safety breakaway couplers (hose lines), hydraulic remote connections for INTRAC layout: auxiliary control valve to front female coupler
13)Comparison Data Sheet: SD 80 / SD 60, sectional views of the SD60 & 80 models
14)Mower Control Valve - mower switched off & on
Pages have a slight wave to them. Manual appears to have been damp. All info is very legible and ready to use!
