Bradco 485 3-point backhoe, back hoe w/12" bucket
Brand New Bradco, Model 485, 3-Point Mounted Backhoe.
* Price is for a Complete 3-Point Mounted Backhoe which Includes:
* 3-Point Mounting Hardware with Solid Top Link.
* Operators Station, Controls & Hydraulic Hoses.
* Grouser Stabilizer Pads.
* The 485 Backhoe is Recommended for Tractors with a Minimum of 30 HP.
* Suitable for Category 1 or 2, 3-Point Hitches.
* High Back Seat is Fully Adjustable.
* Walk Through Operators Platform!
* Swing Function has Speed Control.
* Includes a 2 Year Limited Warranty!!
* Transport Height (w/Boom Fully Retracted) is 81"/6'9".
* Transport Width (w/Stabilizers up) is 51"/4'-3".
* Ground Clearance is 10".
* Overall Length 83"/6'-11".
* Boom Pivot Height is 12".
* Operating Weight with a 12" Bucket is 1200lbs.
* Maximum Digging Depth is 101"/8'-5".
* Digging Depth (2' Flat Bottom) is 100"/8'-4".
* Digging Depth (8' Flat Bottom) is 52"/4'-4".
* Overall Operating Height, Fully Raised is 121"/10'-1".
* Loading Height is 63"/5'-3".
* Loading Reach is 58"/4'-10".
* Reach From Swing Post is 127"/10'-7".
* Bucket Rotation is a Full 180 Degrees.
* Swing Arc is a Full 180 Degrees.
* Stabilizer Spread in Operating Position is 90"/7'-6".
* Stabilizer Down Below Grade is 10".
* System Relief Valve Setting (PSI) is 2750lb's.
* Digging Force of Bucket Cylinder is a Whopping 3895lbs!!!
* Digging Force of Dipperstick Cylinder is a Whopping 2358lbs!!!
Plus, we are Very Glad to say This Backhoe is Made in the USA!!!
