Oz~logan 10" lathe #200, #210 parts manual
"#200 #210 Lathe Parts Manual"
This is a reproduction, not a photocopy, of an original Logan #200 and #210 Lathe Parts Manual. This manual contains complete parts list and exploded views of the lathe. This is a very good manual that covers everything stated below in the contents.
Headstock Assembly..............................1
Reverse Gear Assembly.........................2
Change Gear Assembly..........................3
Shifter Rack Assembly...........................4
Guard Assembly....................................5
Apron Assembly....................................6
Saddle Assembly...................................7
Compound Rest Assembly.....................8
Threading Dial Assembly........................9
Tailstock Assembly..............................10
Bed Assembly......................................11
Bench Stand Assembly........................12
Floor Stand Sets..................................13
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
