Oz~15" drill mill manual-jet,enco,grizzly,msc,asian
"15 Drill Mill Instructions and Parts Manual"
This is a reproduction of an original Asian 15" Drill Mill Instruction and Parts Manual. This machine is manufactured in Aisa and has been sold under many different names including: JET, Grizzly, Enco, MSC, etc... This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list.
To help identify your machine I am posting a picture plus a specification sheet of the size and speeds of the machine. Please do not email me and ask me if this matches your lathe by a model number of some company. I have provided all the information I have. The only way I can help you find which manual fits your machine is to send me a picture by email or postal mail.
1. Cleaning & Lubricating...................................1
2. Mounting Machine.........................................1
A.) Adjustment of Head.....................................2
B.) Preparing JET-15 for Drilling........................2
C.) Preparing JET-15 for Milling........................3
4. ADJUSTING TABLE SLACK.....................3
5. Spindle adjustment.........................................3
6. Speed Changing.............................................4
A.)Removing face mill or drill chuck arbor...........4
B.)To install face mill or chuck arbor...................4
C.)Removing taper drills.....................................5
8. Threads specificatio........................................5
9. T-slots specification........................................5
10. Ordering Replacement Parts.........................5
11. Extra Tooling and accessories.......................5
12. Parts List......................................................7
Headblock Assembly.......................................10
Spindle Assembly.............................................14
Pinion Shaft Assembly......................................15
Table & Base Assembly...................................16
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
