Carrier CES0110060-02 heat pump defrost control board
Carrier CES0110060-02 Heat Pump Defrost Control Board
Carrier CES0110060-02 Heat Pump Defrost Control Board
This is a brand new in the box part.
Contact us for bulk purchase of 5 or more boards.
Heat Pump Defrost Control Board/Circuit Board
This is the Carrier part # CES0110060-02
Heat pump defrost timer. Ultra low cost, Pin-for-pin compatible with OEM controls, Time and temperature control with integral anti-short cycle timer, Outdoor fan and reversing valve relay integrated into design. INPUT: Voltage: 18 to 30 VAC, Frequency: 50/60 Hz, Power Consumption: 1 watt max. OUTPUT: O, W2 Type: Relay, Form: DPST, N.O., Rating: 1 amp @ 30 VAC. T1,T2 Type: Relay, Form: SPST, N.O., Rating: 1 amp @ 30 VAC. OF1, OF2 Type: Relay, Form: SPST, N.C., Rating: 1/2 HP @ 240 VAC. TIME DELAYS: Anti short cycle delay: 5 minutes.
Defrost Time: Fixed 10 minutes ±5%.
Interval Time between defrosts: Pin-selectable 30/50/90 minutes.
Power on Reset Time: 500ms. Test time: short across test terminals reduces test time 256x.
Board Numbers that are replaced by this Circuit Board include: Carrier: CES01130063-00, Carrier: CES01130063-01
Pick up is available for all of our items – Please contact us for more information.
