> Tek DM5120 5520 service and op manuals in 2 res +extras
Tek DM5120 5520 service and op manuals in 2 res +extras
Tektronix DM5120/5520 Service and Operating Manuals in both Very High and in Standard Resolution PDFs on CD
Why settle for just one resolution? You get them both!
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
This PDF Set includes maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams, plus full operating information.
SCAN PARAMETERS (Very High Res PDFs):
Text with photos: 600dpi grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and PCB Photos w/Color (if any): 600dpi 256 color
Scan parameters of the standard res PDFs: The standard res PDFs are done in resolutions that vary depending on individual page content, but are never higher than needed to produce useable quality, quickly navigable files that will do the job without consuming more time and resources than are needed.
"AND IF THAT'S NOT ENOUGH FOR YOU":
As "bonus" material, includes a useful text-searchable scan of the 1990 Tektronix Catalog, featuring almost 3,000 Tektronix Products, at no additional charge!
A text-searchable scan of the service/operating manual for the TM5006 Power Module.
