Tek 7854 very high res a/n and related docs in 2CD set
Five 7854 Application Notes and Five 7854 Related Documents in PDF in a Two CD Set
Why settle for just one resolution? You get them both!
For page samples from this specific set, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
1. "7854 MEASUREMENT PRIMER" A/N 42W-5968 12pgs 106MB (Hi Res)/2MB (Standard Res)
2. "7854 APPLICATION PROGRAMS" Vol 1 #1, July '81 58pgs 84MB (Hi Res)/3MB (Standard Res)
3. "7854 PROGRAMMING PRIMER" A/N 42W-5926 44pgs 164MB (Hi Res)/6MB (Standard Res)
4. "BASIC SOFTWARE PROGRAMS FOR COMMUNICATING BETWEEN THE 7854 AND IBM-PC" A/N 42W-5802-1 20pgs 175MB (Hi Res)/4MB (Standard Res)
5. "MEASUREMENT VARIETY. AN ENGINEERING CHALLENGE FEATURING THE 7854." A/N 42W-4281-1 8pgs 85MB (Hi Res)/2MB (Standard Res)
6. "7854 WAVEFORM PROCESSING OSCILLOSCOPE" Specifications/Ordering Information Brochure 4pgs 47MB (Hi Res)/1MB (Standard Res)
7. "CONSISTENT MEASUREMENTS, AUTOMATIC ANSWERS, FOR ALL YOUR REPETITIVE WAVEFORM REQUIREMENTS" 7854 Sales Brochure 8pgs 134MB (Hi Res)/2MB (Standard Res)
8. "DESIGN YOUR OWN OSCILLOSCOPE SYSTEM" 7000 Series 1985 Selection Guide 18pgs 152MB (Hi Res)/4MB (Standard Res)
9. "TekMAP 7854 TIME AND AMPLITUDE MEASUREMENT SOFTWARE" Specifications/Ordering Information Brochure 4pgs 6MB (Hi Res)/< 1MB (Standard Res)
10. "HOW TO COMPUTERIZE YOUR MEASUREMENTS WITHOUT COMPROMISING RESULTS" TekMAP Descriptive Flyer 1pg 24MB (Hi Res)/< 1MB (Standard Res)
Thank you for considering purchase of these very high-resolution and standard resolution scanned copies of documents as listed pertaining to the Model 7854 Oscilloscope Frame. We supply these PDFs in both a very high res and a faster, less resource-demanding "standard" resolution. The standard res PDFs are TEXT-SEARCHABLE!! Both resolutions are, of course, hyperlinked and use both the chapter-page numbering system and the sequential page numbering system.
SCAN PARAMETERS (Very High Res PDFs):
Text with photos: 600dpi grayscale (contrast adjusted, content-dependent)
Text with Drawings: 400-600dpi black and white
Schematics: 600dpi black and white
Schematics and w/Color Pages: 600dpi 256 color
Chapter-Page -AND- Sequential Page Numbers!
