Analogic dbs 2050A/DBS2050A awg vxi card
Analog signal outputs are available in true differential or single-ended form for one channel
operation and single ended when operating in dual channel mode.
Output amplitudes are 1.0V peak-to-peak using the primary X1 amplifiers; 4.0V
peak-to-peak using the high-level X4 amplifiers. Offsets can be set to ±3.5V with 2 mV resolution.
In addition to the full bandwidth output, the DBS 2050A has three selectable low
pass output filters with cutoff frequencies of 200 MHz, 20 MHz and 2 MHz.
Other filter requirements are accommodated with available SMA feed-thru filter modules.
The sampling clock is built around a precision phase detector capable of synchronizing to internal
The sample clock rate is programmable over a range of 600 S/s to 2.4 GS/s.
The external reference input can range from 2.5 MHz to 100 MHz.
* Sampling Rate: 2.4 GS/s (Single Channel)
* Bandwidth: 800 MHz Typical
* Waveform Resolution: 8 Bit
* Voltage Range: 4.0V peak-to-peak
* Sequence Memory: 4k Segments
* 100% Performance Tested and Regulatory Certified
<>VXI Plug and Play Compliant
This card was tested, and is guarantied to be in good working condition.
