Brown & Sharpe 6" X 18" Visual Grind Form Grinder
Brown & Sharpe Visual Grind
Model No. 618 Micromaster Visual Grind
Serial No. 523-6181-1373, 1963
2-Axis Hydraulic Table Feed
Grinding Capacity: 6" x 14"
Distance of Surface Ground
above Top of Table using Visual Grind: 4-1/2" - 8-1/2"
Max. Grinding Wheel Size: 7" diameter
Table Working Surface: 6" x 18"
Longitudinal Hyd. Feed Rate: 5 to 50 feet per minute
Longitudinal Handwheel, one revolution moves table: 2"
Maximum Longitudinal Travel: 15"
Cross Feed Hyd. Amount: .01 to .25
Cross Feed Rapid Positioning: 10" per minute
Cross Feed Rapid Positioning: 12' per minute
Cross Handwheel Graduations: .0002"
Cross Fine Feed Graduations: .0001"
Maximum Transverse Movement: 7"
Vertical Handwheel Graduations: .0002"
Vertical Fine Feed Graduations: .001"
Vertical Handwheel, one revolution moves grinding wheel: .05"
Maximum Vertical Adjustment: 14-3/4"
Net Weight, approx.: 3,000 lbs.
Upgraded 500 Watt Variable Output Lightsource
18" Diameter Vernier Screen
Walker 6" x 12" Fine Pole Permanent Magnetic Chuck
1HP Cartridge Type Grinding Spindle, 3600 RPM ~ 220/440/3/60
3/4HP Hydraulic Pump Motor
Machine is currently wired 220 volts
All Items Subject to Prior Sale
Be Sure to Verify Specs & Condition Prior to Purchasing
