Tektronix PS2520G tripple output power supply
Tektronix PS2520G Power Supply, Tripple Output
Description: The triple output Tektronix PS2520G Power Supply is a versatile supply suitable for many applications. The PS2520G has a single supply providing a maximum of 6 V and 3 A and two supplies providing a maximum of 36 V and 1.5 A. The PS2520G can be operated in one of three modes: independent, series or parallel. In the independent mode, the output voltage and current of each supply are controlled independently. In the two tracking modes, the variable outputs are connected either in series or in parallel; the controls of the master power supply adjust the voltage or current of both power supplies. The PS2520G is GPIB programmable. The GPIB command sets are SCPI compatible. The power supply features 100 memories to store voltage and current limits for instant recall via the front panel or GPIB. Both have a dual 4-digit LED display.
0 to 6 V, 0 to 36 V (two)
0 to 3 A (6 V), 0 to 1.5 A (36 V)
Programmable voltage resolution
Programmable current resolution
Auto-series/parallel operation
Auto-master/slave tracking
Dual 4-digit panel meter
UL1244, CSA231, EN61010-1
Meets Directive 89/336/EEC
* Cosmetic Condition: Excellent
* Working Condition: Tested good.
* Other Comments / Notes: None
* Warranty: Rest assured that your purchase includes a 3-day DOA Guarantee. If the item is DOA, you will need to notify us within 3-days of receipt. Item(s) must be returned in the same condition as received within 7 days of receipt. (See below for further details).
