Savi smr-650 series savi mobile/fixed rf reader smr-650
SAVI SMR-650 SERIES SAVI MOBILE/FIXED RF READER SMR-650
Brand New - (Item's never been used)
Brand New (Item's never been used)
Double Bubble Wrapped + Corrugated Container
SAVI SMR-650 SERIES SAVI MOBILE/FIXED RF READER SMR-650, DRIVER CD, POWER CORD, MOUNTING GUIDE, SOFTWARE CD, SYNC CRADLE, USER MANUAL, USER GUIDE, AC ADAPTER, POCKET GUIDE, QUICK REFERENCE GUIDE, CLIENT TOOLS SOFTWARE CD, ITV SERVER GUIDE 2004, AIT/RFID OPERATIONS GUIDE 2004, SAVI DOCKING STATION USER GUIDE
Everything you need for a complete mobile RF inventory management system. Complete and brand new.
2qty)- RF RELAY BOX-MODEL#RFR-100, SN:(a)804120028,(b)804120127
DOCKING STATION-MODEL#SDS-2002, SN:904120195
POWER INVERTER 400W-MODEL#WWT-O400 w/40 AMP SPADE FUSE AND POWER CABLE, 12 VOLT VEHICLE CIGARETTE RECEPTACLE
2qty.) - LONGRANGER 2020 UP-DOWN CONVERTER-MODEL#9700-0002, SN:(a)D011269,(b)D011314
POWDEC AC POWER ADAPTER-MODEL#WP05050I,(INPUT: 100-240VAC,50/60Hz, 0.2A),(OUTPUT: +5VDC/1000mA)
IPS AC POWER ADAPTER-MODEL#CUP36-12 B2, SN:009627,(INPUT: 100-240V~,1.0A 50/60Hz),(OUTPUT: 12V, 2.5A)
SMR-650P-111 POWER ADAPTER CABLE-MODEL#CBL-8100-200-DEX, SN:480775
RF RELAY ANTENNA MOUNTING PLATES (QTY 2)
ALL RF RELAY AND SAVI READER CABLES, INCLUDING POWER CABLE
UP/DOWN CONVERTER HOSE CLAMPS (QTY 2)
TM technology, the Savi Mobile Reader takes
real-time data collection to a new level. The Savi Mobile Reader is an
integrated mobile, low profile, lightweight, battery operated
reader module that is used for the purpose of commissioning,
identifying and configuring Savi RFID tags. The SMR-650 includes a
serial DB-9 interface connector and works in conjunction with a
notebook or desktop PC or other devices with DB-9 RS-232 serial
Dimensions: 6.25 in(L)* x 2.5 in(W) x 1 in(H) - 15.88 cm(L)* x 6.35 cm(W) x 2.5 cm(H)
*Note: Length includes antenna and cable
Weight: 6.4 ounces (181 grams) with clip
Temperature: Storage: -4°F to + 140°F (-20°C to + 60°C) Ambient
Operating: -4°F to + 140°F (-20°C to + 60°C) Ambient; 32°F to + 104°F
Humidity: 5% to 95% non-condensing. IP64 Compliant.
Altitude: Max is 40,000 ft (12,192 m); Rate of change is 2,000 ft (610m) per minute
Vibration: MIL STD 810E Method 514.4, Category10, Procedure 1, Minimum
Shock: MIL STD 810E Method 514.4, Category10, Transit Drop Methods 516.4, per
UHF Range: Up to 200 feet with the SaviTag 600/410 series, line of sight reader and
Modulation: FSK, deviation +/- 50KHz
Data Rate: 27.8 Kbps, 50% duty cycle
Data Coding: Manchester (EBCS/EP) and PCM (BCS)
UHF Air Protocol: EchoPoint Air Protocol 2.1 (Two-way UHF commands; Seal extension
RX Signal: Rx Signal Strength Indicator (RSSI) Supported
UHF Antenna: 50 Ohms matched external helical antenna
Interface: Interface back to network requires mobile computer to be enabled with
wireless or wired docking station.
Protocol: UDAP protocol used to communicate with Savi SmartChain Site Manager.
Frequency Range: 123 KHz, Up to 3.5 feet (1.07 meters) with SaviTag-6XX Series
Data Rate: Avg. 1.6 Kbps, 50% duty cycle
Data Coding: Pulse Code Modulation
Antenna: Integrated on-board ferrite core antenna
Air Protocol: EchoPoint Air Protocol 2.1; EchoPoint Air Protocol 1.1
AC Source for AC wall adapter for charging battery 6 ft. cable;
RFID Reader: Input 110/220 VAC, Output 5V +/- 10%regulated, 300mA
Internal battery: Rechargeable Li-Ion battery (3.7V for @420mAh up to approx. 500
recharging cycles @ 80% or more of full battery capacity). Capacity
sufficient for 3 to 4 days of continuous operation depending on usage
assumption. Battery is non-replaceable by the user.
Indicators: Green LED (Heart Beat and Battery Charge Status; Yellow LED (UHF Valid
Radiated FCC Part 15; RSS 210; ETSI, EN 300 220-1 (433 MHz) and EN 300
Emission: 330 (123 KHz); IEC 60601-1-2; EN 301 489-1
Emission: ESD Compliance (EN 301 489-1)
AC Adaptor: U.S. UL 60950; CSA C22 950; CE EN 60950
HERO Rated min. 4†or more of safe separation distance
U.S. UL1604 (approved for use in Hazardous Locations,
SAVI MOBILE/FIXED RF READER SMR-650
