5 MULTI-SPINDLE DRILL, Clausing 2287, 20", 1.
5 MULTI-SPINDLE DRILL, Clausing 2287, 20", 1.
20" 5-SPINDLE CLAUSING VARIABLE SPEED
DRILL TO CENTER OF CIRCLE................ 20"
THROAT SPINDLE TO COLUMN................. 10"
SPINDLE TRAVEL........................... 6-1/2"
SPINDLE TAPER............................ #3 MT
CAPACITY HAND FEED ...................... 1-1/4" STEEL
CAPACITY WITH POWER DOWN FEED ........... 1-1/8" STEEL
COLUMN DIAMETER.......................... 4"
WORKING SURFACE OF TABLE................. 120" x 24"
OVERALL TABLE SIZE WITH COOLANT THROUGH.. 125-1/2" x 29-1/2"
SPINDLE SPEEDS INFINITELY VARIABLE 2 RANGES:
LOW RANGE............................. 150 - 1000 RPM
HIGH RANGE............................ 300 - 2000 RPM
MAXIMUM STROKE ....................... 5-1/2"
MAXIMUM THRUST ....................... 1919 LBS
FEEDRATE INFINITELY VARIABLE ......... 1/2 - 60 IPM
MAXIMUM RAPID APPROACH ............... 280 IPM
APPROXIMATE WEIGHT ...................... 4000 LBS.
- RAISING & LOWERING OF HEADS THRU ELEVATING SCREW
- T-SLOTTED FIXTURE PLATE FOR EASY SET-UP OF DRILL HEADS POSITIONS ON TABLE
- CLAUSING MODEL: 2217 AIR-HYDRAULIC DOWNFEEDS FOR EACH SPINDLE
- .75 - 1.5 HP, 3 PHASE, 60 CYCLE 440 VOLT SPINDLE MOTORS
INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
CONDITION: **** EXCELLENT ****
Machine Location: HARRISON, NJ
