Delta 36-790 14/16" table saw w/ 50" biesemeyer fence


You can shop for your needs 24 hours a day, 7 days a week.
This is the Brand New in the Box w/ 2 year warranty
The 36-790 includes 7-1/2 HP, 200-220/440 Volts (wired for 220 Volts), 60 hz, Three Phase motor with low-voltage (LVC) push-button station, magnetic starter and automatic reset overload, blade guard, BIESEMEYER® Commercial Fence System, guide bar, miter gauge, 43" x 59" table with two extension wings and fence support extension, instruction manual, **Table has removable table insert with buit-in leveling screws**, **Note: blade will not go completely below table unless youuse a 12" or smaller block-16" blade lowest position is 1.4" above table surface; 14" blade lowest position is 0.4" above table surface**.
* Powerful motor handles the hardest woods.
* Double V-belt drive has 2 speeds for best cutting performance. Motor plate, trunnions and arbor support bracket are constructed of cast-iron for solid support and vibration-free operation.
* Arbor runs on pre-lubricated, sealed ball bearings and raises to the correct height and angle by a rack and wormscrew operating mechanism.
* T-slots on either side of saw blade hold miter gauge securely.
* Trunnion stops, adjustable from the top of the table, assure perfect 90° and 45° settings.
* The three-point locking Fence System ensures the fence will be precisely parallel to the blade and will provide a smooth clean cut accurate to within 1/64th of an inch.
* Motor: (TEFC) 7-1/2 HP, 200/440V (wired 200-220V), 3 Phase, 60 hz
* Blade Speed: 3,000-4,500 RPM
* Max Rip To Right Of Blade: 51-3/16" (1300 mm)
* Max Rip To Left Of Blade: 12"
* Depth Of Cut At 45 Degrees: With 14" blade: 3-1/8" (79 mm)
With 16" blade: 4-1/8" (105 mm)
* Depth Of Cut At 90 Degrees: With 14" blade: 4-1/2" (114 mm)
With 16" blade: 5-1/2" (140 mm)
* Distance, front of table to center of blade: 22-13/16 " (579 mm)
* Table in Front of Saw at Max. Depth of Cut: 14" blade at max. cut: 17-1/8" (435 mm)
* Max Width Of Dado: 13/16" (21 mm)
* Miter Gauge Groove: T-Slot miter gauge groove on either side of saw blade
* Table Height: 33-7/16" (849 mm)
* Table Size: 39-3/8" x 43-1/4" (1000 x 1099 mm)
* Chip Exhaust Opening: 4" O.D. (102 mm)
* Weight: 1500 lbs (680 kg); without fence 1381 lbs (626 kg)
Now available business leases as little as $1000.00 Lease Application
* Most orders are processed the same day but may take up to 1 extra business day to be processed to ensure your item meets quality assurance.
* We use Freight Truck Ground service to a business address or residential address.
* The freight companies are also subject to a number of regulations one being that they are not to give any assistance in unloading from the truck, they are only responsible to get the products to the back of the truck.
* Tracking numbers will be sent if requested. We are not responsible if your email account rejects any email from us as some email is sent in bulk and may be treated as spam.
* We are not responsible for transit time once your item leaves our facility.
* Any problems with hardware beyond our 7 business day return policy must be taken up with the manufacturer and/or carrier/network operator. The contact information to most manufacturers and carriers/network operators is listed in our Manufacturer Info section located below.
