3S0680RB smps power switch - nos
The Power Switch(PS) product family is specially designed for an off line SMPS with minimal external components. The piece consist of a high voltage power SenseFET and current mode PWM IC.
Included control IC features a trimmed oscillator, under voltage lock-out, leading edge blanking, optimized gate turn-on/turn-off driver, thermal shut down protection, over voltage protection, temperature compensated precision current sources for loop compensation and fault protection circuit. compared to discrete MOSFET and controller or R
CC switching converter solution, a Power Switch(PS) can reduce total component count, design size, weight and at the same time increase efficiency, productivity, and system reliability. It has a basic platform well suited for cost-effective C-TV power supply.
• Pulse by pulse over current limiting
• Over voltage protection (Min. 23V)
• Internal thermal shutdown function
• Internal high voltage sense FET
Other part number for same device: KA3S0680RB and 3S0680R
Product datasheet can easily be found on the web.
