Oz~bridgeport series i mill mach manual 2HP variable 1
This is a reproduction, not a photocopy, of an original Bridgeport 2hp. Variable Speed Motor Series I Installation, Operation, and Maintenance Manual. This manual covers the full milling machine. It includes good informations on installing and adjusting all of the major parts. It also covers proper lubrication instructions. It includes the parts for the 2hpVariable Speed Motor as well as operating instructions, installation instructions, and how to change the variable speed belt. The manual covers four other heads and attachments, which are listed in the contents below.
Machine SpecificMachine Specifications 2
Adjustment of Saddle and Knee Gibs 10
Clamping Table, Saddle and Knee 11
Mounting Vari-Drive Attachment to Ram Adapter 14
Power Feed Transmission Engagement Crank 17
General Speed Recommendations 24
6F Longitudinal Power Feed Assembly 44
Longitudinal and Cross Feed Assembly
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions email me or send me a picture first. I
